| Description |
Part # |
Vendor / Mfg |
Comment |
|
|
|
|
| Shortblock Assembly |
|
|
|
| Engine Block |
SVO-M-6010R302 |
SVO |
Semi-Finished; Siamese Bores; Pan Fit Problems |
| Crankshaft |
xxx |
SCAT |
Chinese Casting |
| Connecting Rods |
EAG-CRS5400C3D |
Eagle |
"7/16 ARP Bolts; 2.1"" Journals; 620 Grams" |
| Crank & Rod Bearings |
Clevite |
Fed Mogul |
".0025"" Clearance; 2.100 Journal Diameter" |
| Pistons |
1666602 |
JE Pistons |
"4.125"" Diameter; Dished, Stroker Design" |
| Piston Rings |
xxx |
Fed Mogul |
.043; 1/16; 3mm Gap .024 &.018 |
| Timing Chain |
CS-8289-351W |
RollMaster |
58-2 Links; Favored by Nowak & Duttweiller |
| Fuel Pump Block Off Plate |
#6561 |
Ford Power Parts |
Annodized Black; Ball Milled |
| Harmonic Damper |
0209 S/A |
Romac |
"Alum & Steel; 6-5/8""; Dual 3/4 Bolt Pattern" |
|
|
|
|
| Lubrication System |
|
|
|
| Oil Pump |
302 FMC1100 |
Titan Eng. |
Billet Racing Unit; Geo Rotor |
| Oil Pump Pickup |
Custom/Titan |
Billet Fabrication |
Fabricated on Block; Custom fit to pan |
| Oil Pump Drive |
"5/16"" to 1/4""" |
Titan |
Hardened |
| Oil Pump Spacer |
"2""" |
Titan |
Required For Front Sump |
| Remote Filter Block Adaptor |
Custom |
Dale |
Aluminum; Black Anodized; #10 SS Fittings |
| Pan |
Tiger / Titan |
Billet Fabrication |
"Custom Alum w/ Gates, Windage, Scrapers" |
| Dipstick |
C5AZ-6754-A |
Draille Eng. |
FoMoCo Truck Part Now Obsolete |
| Oil |
10-40 Wt. Petroleum |
Kendall Oil Co. |
" Redline Synthetic @ 4,000 miles" |
|
|
|
|
| Cooling & Charging |
|
|
|
| Waterpump & Crankshaft Pulley |
Custom |
Dale's Restorations |
Alum; Mil Spec Anodized Black; Double Belt System |
| Waterpump |
#8847 |
Edelbrock |
Casting Machined to Bearing. Collet Milled & Pressed |
| Front Cover |
C4AE-6059-B |
FoMoCo |
1964; Semi-Polished & Jet Hot Coated |
| Heater Water Outlet |
# 84775 |
Four Seasons |
Aero Welding Lengthened; Nickel Plated |
| Alternator Bracket |
Custom |
Dale / Aero Welding |
Dale Design; Refabricated in Stainless Steel |
| Alternator Adjustment Arm |
Custom |
Dale / LNL Anodizing |
Dale Design; Steel; Black Chromed |
| Alternator |
Custom |
Star Electric |
"85 Amp, Semi Pol & Beaded Cases; HD Stator & Brngs" |
| Alternator Pulley |
TFP-1 |
Enos Components |
Alum Turbo Fan; Mil Spec Black Anodized; Dbl Belt |
| Alternator Bull Nose |
TFP-1S |
Enos/Aero Welding |
Alum/Turned Down by Aero: Black Anodized |
| External Alternator Regulator |
TFP16 |
Enos |
Black Powdercoat |
| Gates Fan Belts |
#7312 #7320 |
Star Electric |
Requires Top & Bottom Pulley Install w/ Belt |
| Thermostat |
160 Degree |
Stewart |
Drilled w/Three Small By-Pass Holes |
| Thermostat Housing |
360 Degree O-Ring |
CSI Technology |
Left Position For Fan Clearance; Black Pwder Coat |
| Coolant |
Gano in Top Hose |
Redline Oil Co. |
Water & Redline Water Wetter |
|
|
|
|
| Bell Housing & Clutch |
|
|
|
| Bell Housing |
C3AA-6394-C |
FoMoCo/Dale |
6-Bolt; Mod For Narrow Pattern; Pwdrct Black |
| Flywheel |
563-101 |
MaCleod |
Aum & Steel 14# |
| Pressure Plate & Disc |
DF 490030 |
Centerforce |
Dual Friction; |
| Throwout Bearing |
N 1439 |
Centerforce |
Or Federal Mogul 614034 |
**
